Delta HMI DOP-105CQ

Delta HMI DOP-105CQ – 4.3-inch Widescreen TFT Touch Screen HMI – Buy in Bangladesh Optimize your industrial automation with the compact and efficient Delta HMI DOP-105CQ. This 4.3-inch Human Machine Interface features a crisp WVGA (480 x 272 pixels) widescreen display, a powerful 800MHz ARM Cortex-A8 processor, and robust serial communication options, making it a solid choice for a wide range of compact control and monitoring systems. Part of Delta’s DOP-100 Standard Series, it offers essential HMI functionalities for space-constrained applications. Available at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Key Features & Specifications of the Delta HMI DOP-105CQ: Model: DOP-105CQ (C-Type Standard HMI) Display Size: 4.3-inch TFT LCD Resolution (Pixels): 480 x 272 (WVGA) Colors: 16-bit (65,536 colors) Luminance (Brightness): 400 cd/m² (Typical) Backlight: LED Backlight Backlight Life: > 20,000 hours (at 25°C) CPU: ARM Cortex-A8 (800 MHz) Flash ROM: 256 MB RAM: 256 MB Touchscreen: 4-wire resistive type, with a lifespan of > 10,000,000 presses Communication Ports: COM1: RS-232 (supports hardware flow control) COM2: RS-232 (supports hardware flow control) / RS-485 COM3: RS-422 / RS-485 (Total 3 serial COM ports) Note: This ‘CQ’ model typically does NOT include a built-in Ethernet port. USB Slave: 1 (Ver 2.0, Type B, for program download) USB Host: 1 (Ver 2.0, Type A, for USB memory stick) Real-Time Clock (RTC): Built-in (with backup battery CR2032, approx. 3 years life at 25°C) Audio Output: Buzzer (Multi-tone frequency 2K – 4K Hz / 80 dB) Power Supply: 24V DC (-15% to 15%) (Please use an isolated power supply; Supplied by Class 2 or SELV circuit) Power Consumption: Max. 3.5 W Front Panel Protection: IP65 / NEMA4 / UL Type 4X (indoor use only) Cooling Method: Natural Air Circulation (Fan-less) Operating Temperature: 0°C to 50°C (32°F to 122°F) Storage Temperature: -20°C to 60°C (-4°F to 140°F) Software: Programmed with Delta DOPSoft. Dimensions (W x H x D): 137 x 100 x 38.6 mm Mounting Dimensions (W x H): 128.3 x 91.3 mm Weight: Approx. 310 g Certifications: CE / UL Why Choose the Delta HMI DOP-105CQ from Multipurpose Automation Solution in Bangladesh? At Multipurpose Automation Solution, located in Gazipur, Dhaka Division, Bangladesh, we provide genuine and high-quality industrial automation products. Choosing the Delta HMI DOP-105CQ from us ensures: Best Price in Bangladesh: Contact us directly to get the BEST PRICE for the Delta HMI DOP-105CQ in the Bangladesh market. We are committed to offering competitive pricing. Compact & Powerful: Despite its small size, it features an 800MHz Cortex-A8 CPU, offering fast response times and efficient operation for essential HMI tasks. Extensive Serial Communication: With three serial COM ports (RS-232, RS-485, RS-422 support), it provides broad compatibility with various PLCs and industrial devices via serial protocols. Clear Widescreen Display: The 4.3-inch WVGA (480×272) resolution TFT LCD offers clear graphics and ample screen real estate for compact control panels. Robust Industrial Design: With IP65 / NEMA4 / UL Type 4X front panel protection and a fan-less design, the DOP-105CQ is built to withstand demanding industrial environments. Local Availability & Support: Being based in Gazipur, we offer convenient access to this HMI, along with expert technical support to assist with selection, programming, and seamless integration into your systems. Applications: The Delta HMI DOP-105CQ is ideally suited for a broad spectrum of industrial applications in Bangladesh, including: Compact machine control and visualization in various industries (e.g., small packaging machines, textile equipment, basic conveying systems). Data acquisition, logging, and historical trending with convenient data transfer via USB in space-constrained applications. Operator interface for small industrial machinery where primary communication is serial. Integration with Delta PLCs and other brands of controllers using RS-232, RS-422, or RS-485 communication. Price and Availability in Bangladesh: For the BEST PRICE and current availability of the Delta HMI DOP-105CQ, please CALL US at Multipurpose Automation Solution in Gazipur, Dhaka Division, Bangladesh. Our team is ready to provide you with a competitive quote and discuss the suitability of this model for your specific requirements.
