HIOKI Earth Tester FT6031 Dust and Waterproof Earth Testing Meter

HIOKI Earth Tester is a tough and ready-for-the-field, IP67 dustproof and waterproof earth testing meter. Labtex provides the original Hioki Earth Tester at a reasonable price in Bangladesh.Key Features of HIOKI Earth TesterIP67 protected – top of the industryTest all ground types from Class A to Class D with a single-meterWide 0 Ω to 2000 Ω measurement rangeMinimize cabling time with innovative earthing rods and cable winderModel: FT6031-50Brand: HIOKIMade in JapanBasic specifications of HIOKI Earth TesterAccuracy Warranty: 1 Year. To ensure safety, use the optional Test Lead L9787 when making measurements using the two-electrode method.Measurement systemSwitchable between two- and three-electrode methodsMeasurement range20 Ω (0 to 20.00 Ω)200 Ω (0 to 200.0 Ω)2000 Ω (0 to 2000 Ω)Accuracy±1.5 %rdg. ±8 dgt.±1.5 %rdg. ±4 dgt.±1.5 %rdg. ±4 dgt.Earth voltage0 to 30.0 Vrms, Accuracy: ±2.3 %rdg. ±8 dgt. (50/60 Hz), ±1.3 %rdg. ±4 dgt. (DC)Dustproof and waterproofIP65/IP67 (EN60529)Power supplyLR6 Alkaline battery ×4, Possible number of measurements: 400 times (measurement conditions: three-electrode method, measuring 10 Ω)Dimensions and mass185 mm (7.28 in)W × 111 mm (4.37 in)H × 44 mm (1.73 in)D, 570 g (20.1 oz) (including protector and batteries)AccessoriesAuxiliary earthing rod L9840 (2 piece set) ×1, Measurement cable (black 4 m) L9841 ×1, Measurement cable (yellow 10 m, equipped with winder) L9842-11 ×1, Measurement cable (red 20 m, equipped with winder) L9842-22 ×1, Carrying case C0106 ×1, Protector ×1, LR6 Alkaline battery ×4, Instruction manual ×1Dustproof and waterproof enclosure for robust performance in the fieldSince the FT6031’s enclosure is designed to keep out dust, it can be used with peace of mind in settings where it would be exposed to mud and dust. And if the instrument gets dirty, it can be rinsed clean with water.Using a grounding resistance meter: Two- and three-pole methodsYou can select from two grounding resistance measurement methods (two-pole or three-pole). The instrument switches the internal connection automatically when the selection key is pressed, so there’s no need to connect a short bar or other fixture.Three-pole method: Measure grounding resistance after inserting supplemental grounding rods into the ground.Two-pole method: Measure grounding resistance using the Class B ground of a pole-mounted transformer.Dramatically faster measurement setup thanks to superior ease of use and digital operationThe FT6031’s supplemental grounding rods are thinner than previous products, making it easier to insert them into and remove them from, the ground. The rods are made of rigid, corrosion-resistant stainless steel. In addition, the allowable resistance of the supplemental grounding electrodes has been increased by a factor of 10. This enhancement eliminates the inconvenience of setting and resetting the rods over and over again when the allowable resistance is exceeded, for example in dry soil conditions.Digital grounding resistance meter featuring easy operationThe FT6031 is extremely easy to operate: just press the MEASURE key. The instrument will automatically complete the following sequence of operations: ground potential check → supplemental grounding electrode check → grounding resistance measurement. Auto-range operation eliminates the need to switch ranges since the instrument automatically selects the optimal range.
