ACQ80X50 – Compact Pneumatic Cylinder (ACQ Series)The ACQ80X50 is a heavy-duty, compact double-acting pneumatic cylinder in AirTAC’s ACQ line. It features an 80 mm bore and a 50 mm stroke, offering robust pushing force while maintaining a compact form factor. Designed for industrial applications where a large bore is needed but space is at a premium.Key Features:Double-acting for push & pull action.Comes in variants without magnet, with magnet (ACQ80X50-S-PT), and different thread types such as PT or NPT.Female-threaded rod connection.PT thread ports (or other compatible thread types in alternate versions).Built to JIS standards, using “C-clip” connection between body and covers; riveted construction for durability.Internal barrel is hard-anodized for wear resistance.Specifications:ParameterDetailsModelACQ80X50Bore Size80 mmStroke Length50 mmActing TypeDouble-actingMagnet OptionVersions available without magnet & with magnet (ACQ80X50-S-PT)Thread / Port TypeStandard female threaded rod; port thread type PT (variant) or NPT in some modelsOperating Pressure≈ 0.15 to 1.0 MPa (≈ 1.5 to 10 bar)Proof Pressure≈ 1.5 MPaTemperature Range−20 °C to 80 °CSpeed / Flow Range~30 to 500 mm/sCushion TypeBumper cushion (standard)Applications:ACQ80X50 is well suited for situations where:High thrust is needed over a short strokeSpace or length is limited but force is non-negotiableIntegration with sensors is required (if using magnet variant)Heavy-duty industrial machinery, presses, clamps, or automation with large loads SKU: ACQ80X50 Categories: Industrial Automation, Pneumatic Components
