AirTAC ACQ40X10 – Compact Pneumatic Cylinder
$19.25
$31.57
ACQ40X10 – Compact Pneumatic Cylinder (ACQ Series)The ACQ40X10 is a compact, double-acting pneumatic cylinder in AirTAC’s ACQ series, designed to deliver reliable linear motion in constrained spaces. With a 40 mm bore and a 10 mm stroke, it’s built for applications needing a strong pushing force over a short distance. The standard version is built without magnet, and comes with a female PT thread rod.Key Features:Compact body, ideal for tight mounting spaces.Double-acting design (push & pull on both ends) for precise control.Female threaded rod (PT thread) for standard fittings.JIS standard is implemented.“C-clip” construction linking body parts, giving strength and compact assembly.Specifications:ParameterDetailsModelACQ40X10Bore Size40 mmStroke Length10 mmActing TypeDouble-actingMagnetWithout magnet (standard version)Rod / Thread TypeFemale thread, PT thread typeOperating Pressure~0.1 to 1.0 MPa (≈ 1.0–10.0 bar) (double-acting)Proof Pressure~1.5 MPaTemperature Range−20 °C to 80 °CSpeed Range~30 to 500 mm/sCushion TypeBumper (standard)Port Size / Thread OptionsPT 1/8 (others available)Applications:Because of its short stroke and large bore, the ACQ40X10 is best suited for:Quick, short travel linear actuationClamping, pressing, or positioning tasks where the distance moved is small but force required is highTight/compact assemblies or fixtures where space is limitedApplications where sensors might be added later (optional magnet version available) SKU: ACQ40X10 Categories: Industrial Automation, Pneumatic Components
