UNI-T UT890C RMS Multimeter With Temperature Tester. The UT890 series 6000-count true RMS digital multimeters are designed with a large LCD. The maximum measurable capacitance is 100 μF, with a fast response time of less than 12 seconds. The NCV and continuity measurement have acousto-optic indications. UT890C or UT890D has a LIVE function for distinguishing between live and neutral wires. Additionally, it is equipped with automatic fuse-blown detection and high-voltage protection. Models in UT890 Series: UT890C, UT890D Features of UT890C Digital True RMS MultimeterManual range/True RMSData hold/RELAudible/visual alarm (NCV/continuity)Current (AC/DC) mode memoryLow battery indication: ≤2.5VNCV/hFE/Max/MinDiode test/Continuity testHigh voltage false detection: 1000VrmsOver-current alarm: ≥20AAuto power off/LCD backlightSpecifications of UT890 Series Digital True RMS MultimetersSpecificationRangeUT890CUT890D DC Voltage600mV/6V/60V/600V/1000V±(0.5% 2)±(0.5% 2)AC Voltage6V/60V/600V/750V±(0.8% 3)±(0.8% 3)ACV Frequency10Hz～10kHz±（0.1% 5)±（0.1% 5)DC Current60uA//600uA/6mA/60mA/600mA/20A±(0.8% 8)±(0.8% 8)AC Current60uA/600uA/6mA/60mA/600mA/20A±(1% 12)±(1% 12)Resistance600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ±(0.8% 3)±(0.8% 3)Capacitor6.000nF/60.00nF/600.0nF/6.000μF/60.00μF/ 600.0μF/6.000mF/60.00mF/100.0mF±(3% 10)±(3% 10)Frequency9.999Hz～9.999MHz±(1.0% 5)±(1.0% 5)Temperatue–40℃～1000℃/–40°F～1832°F±(1.5% 5)FeaturesDisplay Count60006000Manual Range√√NCV√√hFE√√Diode Test√√Continuity Test√√Live√True RMS√√Fuse blowing alarm√√Acousto-optic indication(NCV/continuity)√√High voltage false detection1000Vrms√√Current (AC/DC) mode memory√√Over-current alarm≥20A√√Low Battery Indication≤2.5V√√Data Hold√√REL√√Max/MinV 、A√√Auto Power Off15Min√√BacklightThe 30s√√Operation Temperature0℃～40℃SafetyCAT II 1000V/CAT III 600VGeneral CharacteristicsPower1.5V x 2Product ColorRed and GrayProduct Net Weight346gProduct Size183mm x 88mm x 56mmStandard Individual PackingGift Box, ManualStandard Quantity Per Carton40pcsStandard carton measurement690mm x 450mm x 340mmStandard carton gross weight23KgApplications of UT890 Series True RMS MultimeterLive and nature wires identificationVoltage measurementTemperature measurementNCV measurementand many more.Click for More Information
