UNI-T UT201 Digital Clamp Meter DMM AC DC Auto Range Ture RMS Handheld Digital Multimeter Tester Volt Ohm Meter. UNI-T UT201 is a True RMS clamp meter that measures AC and DC voltage, AC, resistance, and continuity, and also may be used for diode checking.AC CurrentAC/DC voltageresistancecontinuity testdiode testTrue RMS measurementAudiovisual NCV detectionLarge LCD.Full-featured false detection protection for up to 600 V energy surges; overvoltage and overcurrent alarm functions.The power consumption of the meter is about 1.8 mA. The circuit has an automatic power-saving function. The consumption in the sleep state is <11 μA, which extends the battery life to 400 hours.Low battery indication.Automatic power after 15 of no-operation (function can be turned off).Data hold function.Max/Min mode.Specifications:DC Voltage: 200mV/2V/20V/200V/600V, ±(0.8% 1)AC Voltage: 2V/20V/200V/600V, ±(1.2% 5)AC Current: 2A/20A/200A/400A, ±(1.5% 5)Resistance: 200W/2kW/20kW/200kW/2MW/20MW, ±(1% 2)Frequency:10Hz~10MHz,±(0.5% 3)General Characteristics:Power: 1.5V Batteries (R03) X 2 (Not Included)LCD Size: 35.6 X 18mmProduct Color: Red And Grey ProductNet Weight: 220gProduct Size: 210 X 75.6 X 30mmStandard Accessories: Test Lead, Manual
