Description TSA200 is 1-Wire current loop transmitter with 0-20mA/4-20mA input range. The current loop input is galvanically isolated from the interface.The device communicates over a 1-Wire bus. Each sensor has a unique 64-bit serial code. This allows multiple sensors to be connected on the same 1-Wire bus. The 1-Wire current loop transmitter TSA200 has two RJ11 connectors for a daisy chain of multi-sensors systems. TSA200 can be connected to almost any industrial sensor with a 0-20/4-20mA output. Output readings in mA can be converted to other units, using offset and multiplier of the controller.The sensor can be used for measuring of electrical and non-electrical parameters – liquid levels, air pressure, gas concentration, illumination, acidity (pH), etc. TSA200 is a passive device, for some applications external DC power supply will be needed – typically 12/24/36VDC. Features Galvanic isolated current loop input from 1-Wire interface; 10-bit resolutions; Excellent long-term stability; IP30 ingress protection; Very low current consumption; Unique 64-bit serial number for multi-sensors support. 1-Wire current loop transmitter TSA200 (v2.6) TSA200 3D model (v1.0)
